11042-OR | PML Cover Valve Covers For Chevy Big Block, 396, 427, 454, 502, CHEVROLET Script, Tall | Orange Powder Coat Finish

Price for set of 2 covers. Includes mounting bolts. Does not include gaskets.

Check for clearance to firewalls, brake bosters, alternator, air conditioning brackets, and the like.

Number of Bolts:

7 per cover, on the perimeter

Finishes:

These tall, heavy duty valve covers from PML for big block Chevy engines feature raised CORVETTE script and fins and top quality construction. The classic CORVETTE script is licensed from General Motors.

Benefits:

• Traditional CORVETTE script and sand cast aluminum construction for an old-school look and feel
• Taller than standard height and open interior to work with many roller rockers
• No brake booster indent
• PCV and oil fill/breather holes
• Holes have internal baffles cast to reduce oil blow-by
• Thick walls and gasket flanges for strength and a secure seal to the cylinder head
• GM licensed product

Chevrolet big block engines include: 396, 427, 454, and the 502

These valve covers are a bit taller than stock without oil drippers and no brake booster relief to fit over many roller rockers. Always verify clearance before ordering. Using double gaskets to add height frequently causes leaks. Customers have reported to us that PML tall valve covers eliminated the need for double gaskets and the leaks.

For covers with a brake booster relief, see PML regular, standard height valve covers with CORVETTE script and fins, PML Part Number 9096.

PML designed these valve covers using original GM cast iron heads. Chevrolet Big block engines include: 396, 427, 454, and the 502.

These valve covers are taller than stock so check for space for larger valve covers.

If using updated Camshaft or roller rockers, some modification may be needed.

Gaskets

Gaskets are not included with these valve covers. PML designed these Chevy Big Block valve covers to work with cork composite gaskets.

Breather and PCV Holes

PML Chevy big block valve covers have PCV and oil fill/breather holes and baffles cast into the covers. The internal baffles help prevent oil blow-by out the PCV and breather holes.

These holes work with standard 1 1/4 inch grommets.

If desired, a breather cap with a 1 inch outer diameter tube can be used with the breather grommet.

Checking Clearance

Engine configurations vary so please check for clearance for larger valve covers. The walls and gasket flange are thicker than stock and the fins and script add height to the top.

Look for clearance on the inside also, especially if you have roller rockers. A simple check can be made if you have the stock valve cover. Set the stock cover on the head and measure the distance, if any, between the gasket flange surface and the head. This cover is approximately 3/8 to 1/2 inch taller than the stock cover. PML tall covers are approximately 3/8 inch taller than our standard height covers.

Some customers have reported that their roller rockers contact the inside of these PML valve covers at corners. PML has heard that grinding a bit off the roller rockers on #1 intake and #6 intake, one intake rocker on each side of engine, can add enough clearance (but this is not something we have tried or endorse).

Because these covers are larger than stock, on some Corvette engines, you may need to remove the alternator to install these covers. Accessing some of the bolts may be difficult.

These valve covers do NOT have a relief for the brake booster. See regular, standard height valve covers if a relief or indent for the brake booster is needed.

Inside of Valve Covers

Always check your engine configuration for clearance requirements before ordering.

These valve covers feature an open interior for clearance for many roller rocker systems. There are no old drippers or brake booster relief for maximum internal height and space.

The baffle for the PCV and breather holes is part of the casting. There are not any screws or plates to come loose.
